Whynter 17'' CoolSize 10000 BTU White Compact Portable Air Conditioner

ARC-101CW

Regular price $760.00
Sale price Regular price $499.00
SHIPPING: FREE
You save Save $261.00 (34%)
/

trust badges

Description

The Whynter CoolSize 10000 BTU Compact Portable Air Conditioner is the ideal space-constrained climate-control solution. Designed with a compact modern style and a rounded child-friendly profile, the unit easily blends in with any room design and is ideal for a kid’s room. This compact, yet powerful portable air conditioner can also function as a 70-pint dehumidifier to remove excess humidity from the air, allowing the ambient air to feel even cooler and improving air comfort.

Eco-Friendly
With this Eco-friendly CFC-free, lead-free and high energy efficiency portable air conditioner, you can stay cool while keeping with better environmental standards and reducing energy consumption.

Hassle-free operation
The Whynter ARC-101CW portable air conditioner features a patented advance auto drain technology, which uses and recycles moisture collected during the cooling process to produce cool air. Furthermore, direct drain option allows you to continuously use the unit year-round when the dehumidifying function may face a heavier work load.

Automatic Restart
The auto restart function stores your selected settings so that in the event of a power interruption, the portable air conditioner will restart just as before when the power comes back on.

Storage cover bag
Comes with a protective cover with pocket that will protect your portable AC unit plus store your exhaust hose, window kit, remote control and user manual when not in use. This protective cover will keep dust and dirt from collecting on the unit while it is in storage.

Useful features
Equipped with a remote control that can easily control the speed, temperature, timer and dehumidifier settings even from a distance, the Whynter ARC-101CW also comes with rolling casters that will allow you to move the portable air conditioner room to room.

This unit can cool up to a 300 sq. ft. space (ambient temperature and humidity may influence optimum performance).

Additional Information

ASHRAE BTU

10,000 BTU

Color

White

Coverage Sq. Ft.

300 sq. ft.

Dehumidifying Capacity

70 pints/ day

Exhaust Hose Length

Max. 59"

Fan Speed

3 speed

Filter Type

Carbon air filter and washable pre-filter

Heat Mode

No

Hose System

Single Hose

Louver Type

Fixed

Maximum Power Consumption

1000W / 9.4A

Noise level (dBA)

< 55

Pump Feature

No

Refrigerant

R-410A

Replacement Filter

Carbon: ARC-CF-TYPE-M

Replacement Hose

ARC-EH-TYPE-101

Replacement Window Kit

ARC-WK-SINGN

Storage Bag

N/A

Temperature Range

61°F – 89°F

Upper Gravity Drain Port

Yes

Window Kit Length

6.5" W x 20" (min)/ 46" (max) L

SACC BTU

5,214.9 BTU

Unit Dimensions

19" W x 13 ½" D x 29 ⅛" H

Features & Specification

Frost White color
● 10,000 BTU Cooling
● ECO-FRIENDLY CFC free GREEN R-410A refrigerant
● Lead free RoHS compliant components
● Patented auto drain function fully exhausts all condensate automatically in most environments
● Three operational modes: Cool, Dehumidify, and Fan
● Digital and remote control
● LCDI (Leakage-Current Detection and Interruption) plug
● Dehumidifying Capacity: 70 Pts / day
● Upper and lower drain ports for continuous operation
● Designed to provide quiet and efficient cooling to any room, with no permanent installation
● 3 speed fan
● Equipped with an Activated carbon filter and washable pre-filter
● Full thermostatic control (61°F – 89°F)
● Casters for easy mobility
● 24 hour programmable timer
● Noise level (dBA): <55
● Auto restart after power outage
● Storage cover bag with pocket
● Extendable exhaust hose (up to 59″)
● Upgraded Plastic window kit included
● Exhaust Hose: 5.5″ diameter
● Hose Connectors: 5.5″ diameter with 5.0″ diameter reducer
● Fixture and Window Kit: 5.0″ diameter
● Window Kit: 6.5″ W x 20″ (min)/ 46″ (max) L
● Storage cover bag with pocket
● Air Flow (at high speed): 264m3/h / 145CFM
● Maximum cooling power consumption: 1000W  / 9.4A
● Power supply: 115 V / 60Hz / 1 Phase
● Unit dimensions: 14″ W x 19″ D x 30″ H
● Package dimensions: 16″ L x 24″ W x 31″ H
● Net weight: 53 lbs
● Gross weight: 68 lbs
● UL listed
● UPC 850956003873

Resources & Manual

USER MANUAL

Troubleshooting

FAQs

Accessories

Intake / Exhaust hoses: Based on the version of the portable air conditioner you have, you may need a 5.0″ or 5.5″ diameter hose(s) and/or connector(s) listed below. Please make sure to measure your existing hose(s) before ordering additional accessories.

NOTE: Please note that we do not recommend extending the exhaust hose(s) more than 9 feet long.

ARC-EH-TYPE-S
(Whynter Intake / Exhaust hose 5.0″ diameter)
Available at:
Ambient Stores
Amazon.com


ARC-EH-TYPE-101
(Whynter Intake / Exhaust hose 5.5″ diameter)
Ambient Stores


Window Slide Bars: ARC-WK-SINGN
Whynter Plastic Window Kit 6.5″ W x 20″ L (minimum), 46″ (maximum)
Available at:
Ambient Stores
Amazon.com


Activated Carbon Filter: ARC-CF-101CW

Whynter Activated Carbon Filter
Available at:
Ambient Stores
Amazon.com


Storage Bag: ARC-STRGBG-B
Whynter portable air conditioner storage bag
Available at:
Ambient Stores


Optional Lower Drain Bucket: ARC-DB

Whynter optional drain bucket for manual draining from lower drain port
Available at:
Ambient Stores
Amazon.com


Optional Upper Drain Hose: ARC-TYPN-UDPH
Whynter optional upper drain hose for continuous gravity drainage setup
Available at:
Ambient Stores


Complete Accessories Set: ARC-ACC-SISETCW-V2

Complete Ventilation Set for ARC-101CW
Available at:
Ambient Stores
