Trapeze
| Duct Discharge | Vertical |
|---|---|
| Duct Size; Vertical; IN | 8 |
Product Dimensions
| Dimension | Measurement |
|---|---|
| Net Height; IN | 34 - 52 |
| Net Width; IN | 60 |
| Nominal Width; IN | 60 |
| Net Depth; IN | 26.625 |
| Weight; LBS | 92 |
Features
| Feature | Definition |
|---|---|
| Multiple Blower Options | Multiple blower options are available to fit your application. |
| LumiLight LED Lighting | LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours. |
| Directional Lighting | The light bulbs can be adjusted to direct light over cooking surface where it is needed the most. |
| Professional Baffle Filters | High-airflow baffle filters that are dishwasher safe and ensure a lifetime of exceptional performance. |
| Electronic Touch Controls | |
| Optional Wireless Remote Control | Our wireless remote control places the hood's operations at your fingertips from anywhere in the kitchen. |
| Optional Extension Duct Cover Kit | Extension duct cover kit to accommodate ceiling heights up to 12 ft; see spec sheets for more details. |
| Energy Star Certified | No |
Blower CFM and Sones
| Blower | Specification |
|---|---|
| Blower Included | No |
| Internal Blower 1 CFM | 290 |
| Internal Blower 1 Min. Sones | 1.4 |
| Internal Blower 1 Max Sones | 3 |
| Internal Blower 2 CFM | 600 |
| Internal Blower 2 Max Sones | 6 |
| In-Line Blower CFM | 1000 |
| External Blower CFM | 1000 |
Warranty
| Parts / Labor | Duration |
|---|---|
| Warranty Parts / Labor | 3 / 1 |
